Automatic Inline Strapping Machine - 50000 Series
Automatic Side Seal Strapping Machine Designed for Can, Bottle, Paper and Beverage Industries
The FROMM 50000 series strapping system features the strapping head on the side, facing the product.
The 50000 is popular with the beverage industry for PET, aluminium and glass containers as well as general for strapping or logistic distribution.
The 50000 series offers easy access to the strapping head, which can be fixed or designed to stroke (up to 450mm) to apply the face of the product.
The strapping machine is available in its simplest format and with lots of add on's to meet customer needs depending on the application.
Two Year Warranty
Simulation Testing
5 Star Rated
Environmentally Friendly
Features
- Strapping head on side
- Suitable for PET (plastic) or steel strap
- Automatic and manual functionality
- Siemens controls and touch screen
- Modular with many add on features
- Fast strapping cycle
Benefits
- Plug and play technology
- High production capacity
- Extensive customisation and options available
- Fast and simple roll changes
- FROMM 2 year warranty
- 150,000 service intervals
- On screen fault finding
Specification
Dependent on conveyors
Unlimited
Friction, up to 85% of strap breaking strength
9 - 32 mm
0.40 - 1.35 mm
105 mm / second
7000 Newtons
12 - 32 mm
18000 Newtons
Options
Fixed or Gated
Fixed or Floating
Top or Side, Top and Side
1000 - 5000 kg
Standard, jumbo or superjumbo
Top and bottom corner applicators
Magazine or Robot
Automatic Head Cleaning
Fixed track or bayonet to strap through the pallet
FROMM plastic strapping is manufactured in one of our global production centres using almost 100% recycled polyester resin. Extruded on one of our state of the art production facilities, FROMM uses RPET resins with high IV values. Strapping can be offered on small 20 kg coils up to 250 kg super jumbo rolls.
Reuse: PET straps are not generally reused in their original form, but they contribute to a sustainable cycle. Once the strapping has served its purpose, it can be collected, recycled, and transformed into new, high-quality products, helping to minimise waste.
Reduce: By choosing lightweight PET straps, designed for our machines and tools, businesses can lower transportation emissions and decrease material usage, contributing to a more sustainable packaging solution.
Recycle: Fully recyclable, our PET straps support a circular economy. After use, they can be processed into new products, reducing landfill waste and promoting sustainability.
